I have a CJ-5 transfer case with the 1 1/4" shaft intermediate gear. However, the tooth count is 34x21. The same as a CJ-3 with a 1 1/8 shaft. The CJ-5 intermediate gear with 1 1/4" shaft that you sell has a tooth count of 39x18. This will not fit to my existing side gears. Do you know how I can find a replacement intermediate gear for it? A 34x21 with 1 1/4" shaft intermediate gear.
Willys Jeep Parts Tech:
Email mike@Kaiserwillys.com to help out on.
Email mike@Kaiserwillys.com to help out on.
Can an intermediate shaft gear with a 34 x 21 tooth count be swapped with 39 x 18. I have a 53 CJ3A and purchased a used transfer case from a 47 CJ2A that according to the charts should be compatible. When I received the used case, ordered unseen, the tooth count is different on the gears. I'm wondering if the transfer case in my 53 has been previously changed out. Any suggestions?
Willys Jeep Parts Tech:
You need to stick with the proper gears for the shaft size on your intermediate. They do not interchange.
You need to stick with the proper gears for the shaft size on your intermediate. They do not interchange.
Yes, typically we have these in NOS or new US made.
Be the first to answer this question.
My old gear is 34x21 tooth count, With 1-1/8 shaft. Will your new gear have the correct bore for the 1-1/8 shaft?
Willys Tech:
Yes, this is the 1-1/8 shaft size gear.
Yes, this is the 1-1/8 shaft size gear.
is the bore in the gear all the same size? AS There are different size intermediate shafts.
Willys Tech:
Yes because they have to accommodate the different shaft sizes - 3/4, 1-1/8 or /-1/4.
Yes because they have to accommodate the different shaft sizes - 3/4, 1-1/8 or /-1/4.
